產品應用：
WIPOUS ® CABLE EV電動汽車充電電纜用于連接電動汽車、充電裝置與充電基礎設施，從而對電動汽車進行電力傳輸，并配備一定數量的信號線、控制線、電源輔助線等來確保整個充電過程控制準確、操作安全無誤。充電電纜一般使用于充電站、停車場、酒店、小區、車庫等區域，便攜式充電電纜可放置在車內。
| 絞合導體 | 導體 | 絕緣 | 屏蔽 | 20°C最大導體電阻 | 標準長度 M |
||||
| 面積 | 線數/線徑 | 外徑 | 標稱厚度 | 標稱外徑 | 編織結構 | 護套外徑 | |||
| mm2 | NO./mm | mm | mm | mm | mm | Ω/km | |||
| EV 1*0.5 | 28/0.15 TR | 0.92 | 0.69 | 2.30 | 16/6/0.10 TXR | 4.30 | 37.10 | 1000 | |
| EV 1*0.75 | 24/0.20 TR | 1.13 | 0.64 | 2.40 | 16/6/0.11 TXR | 4.50 | 24.70 | 1000 | |
| EV 1*1.0 | 32/0.20 TR | 1.4 | 0.65 | 2.70 | 16/6/0.12 TXR | 4.70 | 18.50 | 1000 | |
| EV 1*1.5 | 48/0.20 TR | 1.62 | 0.69 | 3.00 | 16/8/0.10 TXR | 5.10 | 12.70 | 1000 | |
| EV 1*2.0 | 64/0.20 TR | 1.85 | 0.68 | 3.20 | 16/8/0.10 TXR | 5.30 | 9.42 | 1000 | |
| EV 1*2.5 | 80/0.20 TR | 2.06 | 0.77 | 3.60 | 16/8/0.10 TXR | 5.60 | 7.60 | 1000 | |
| EV 1*4.0 | 82/0.25 TR | 2.85 | 0.68 | 4.20 | 16/8/0.12 TXR | 6.40 | 4.71 | 1000 | |
| EV 1*6.0 | 122/0.25 TR | 3.47 | 0.87 | 5.20 | 16/8/0.12 TXR | 7.70 | 3.14 | 1000 | |
| EV 1*10 | 204/0.25 TR | 4.51 | 1.10 | 6.70 | 16/8/0.12 TXR | 9.30 | 1.82 | 1000 | |
| EV 1*16 | 326/0.25 TR | 5.9 | 1.05 | 8.00 | 16/8/0.15 TXR | 10.70 | 1.16 | 1000 | |
| EV 1*25 | 509/0.25 TR | 7.4 | 1.20 | 9.80 | 24/8/0.15 TXR | 12.90 | 0.74 | 1000 | |
| EV 1*35 | 713/0.25 TR | 8.8 | 1.30 | 11.40 | 24/8/0.15 TXR | 14.50 | 0.53 | 1000 | |
| EV 1*50 | 1018/0.25 TR | 10.5 | 1.50 | 13.50 | 24/10/0.15 TXR | 17.00 | 0.37 | 1000 | |
| EV 1*70 | 1426/0.25 TR | 12.5 | 1.60 | 15.70 | 24/10/0.15 TXR | 19.80 | 0.26 | 1000 | |
| EV 1*95 | 1887/0.25 TR | 14.6 | 1.80 | 18.20 | 24/8/0.20 TXR | 22.60 | 0.20 | 1000 | |
| EV 1*120 | 2368/0.25 TR | 16.4 | 1.80 | 20.00 | 24/8/0.20 TXR | 24.80 | 0.15 | 1000 | |
